產品編號:
YC-181
產品名稱:
YC-181 chemical anchor bolt
規  格:
產品備注:
產品類別:
EXPORT PRODUCTS

   產 品 說 明

(1)YC-181 chemical anchor bolt contains vinyl resin, well-selected

quartz sand, curing agent powder in a small capsule, these components

are put in a bigger glass tube,be used togetherwith the certain dimension

metal bolt. It is a new anchoring materials, a substitution for embedded parts

and the expansion screw.

(2)Features

 Quick and stable anchoring;

 Strong tensile strength, suitable for heavy loading;

 Non-swelling, fit to kinds of base materials;

 Fully glued with the substrates, anti-wear of passivity;

 Acid resistance, anti weathering, anti aging;

 Can be used in wet and moist conditions;

 Excellent thermostability;

 Safe and simple operation in construction;

 A wide range of construction temperature from 10℃ to 40℃.

(3)Application range

Install metal posts into the concrete substrate; Install beams (of steel material or wood)

onto concrete post or wrapped panels; fix stone hanging board, curtain wall;

Install protective rail, railings, large outdoor display panel, advertising

poster board, vertical rod, equipment, support track and conduit.

(4). Installation Date Sheet

Construction and Installation Data Sheet

Model

M8

M10

M12

M16

M20

M24

M30

Anchor bolt diameter(mm)

8

10

12

16

20

24

30

Anchor bolt length (mm) L

110

130

160

190

260

300

380

Drill borehole diameter (mm) dB

10

12

14

18

25

28

35

Embedment depth (mm) t

80

90

110

125

170

210

280

Thickness of fixture (mm) Smax

14

20

25

35

65

65

70

Min. substrate thickness(mm) d

130

140

160

175

220

260

330

Max. tightening torque Mp(Nm)

10

20

40

80

150

200

400

If necessary, hole depth and strength could be increased according to the specific requirements



(5). Solidification time(after which the drawing test can be conducted)

Temperature

> 20

10-20

0-10

-5-0

Dry concrete

10min

30min

60min

3h

Wet concrete

30min

60min

2h

8h





We have two products been exporting to Southeast Asian countries,

customers from United States have recognized the quality of these two products.

If you have any questions about our products, don not hesitate to contact us at 86-21-67354586-828.

18321506539



For more details, please contact us at office@yoscon.com.
